Reveles singularem observantiam Box Optronicorum' 980nm 10pin mini papilio refrigeratum sentinam laser diodae moduli – solutionem ultimam tuam pro summus potentiae, necem-stabilis crepitans in DWDM EDFA et longum bolum CATV systemata. Machinatus cum provecta stabilizatione FBG, hic hermetice obsignatus comas moduli emissione praecise ad 974nm vel 976nm, liberans kink-liberum output usque ad 600mW vel sub varia temperie et vena pellunt. TEC, thermistor, et monitor Diode integra eius erroris et potentiae stabilitatem sequi possunt, dum epoxy liberorum 10-clavum papilionum sarcina cum SM/PM fibra certas operationes liberas, sonitus praestat. Disposita ratio integratorum et machinarum retis postulans spectrum promissum imperium et supremas facultates promptas, cuius moduli computationes sentinarum percutit, multiplicitatem refrigerationem minuit, et spatium amplificantis extendit. Spera Box Optronici pro Telcordia GR-468 obsequium et adaequationem delectu formandam – quia omnis milliwatt res in reticulis opticis proximis generationis. Praecipe nunc ut infrastructuram tuam cum probatis, campi technologiae paratae flare, quae congruenter ab -20°C ad 75°C perficiendam tradit.
980nm 10pin mini papilio refrigeratum sentinam laser diode moduli hermetically in epoxy libero et fluxu libero 10-pini papilionum sarcinam construxit et in thermistore, thermoelectric frigidiore et monitor diode.
Quod 980nm 10pin mini papilio refrigeratum sentinam laser diode moduli utitur FBG stabilization ad " clausum" emissio necem est. Id prospicit spectrum angustum liberum, etiam sub mutationibus temporis, currentis et opticalis commodis agitet. Neca selectio is est pro applicationibus quod require pro summa perficiendi in spectrum potestas summae potestatis est. Modulus hic obsecutus est in Telcord ia GR-468-CORE descriptus postulationem.
Kink-libera potentia operativa 400mW vel 600mW;
Involucrum papilionis 10-PIN cum SM Hi1060 vel PM980 fibra;
Fibra Bragg craticulae stabilizatio, Necem lectio available;
Integrant thermoelectric frigidior, thermistor et monitor diode.
Densa necem divisio erbium multiplexing(DWDM) fibra amplificata (EDFA);
Reducuntur sentinae architecturae EDFA computant;
Longissimum intervallum funis television(CATV) truncorum et altissima nodi distributio computat.
| Parameter | Symbolum | Min. | Typ. | Maximilianus. | Unitas | Notae |
| Causa operating temperatus | TCASE | -20 | - | 75 | ℃ | - |
| Repono temperatus | TSTG | -40 | - | 85 | ℃ | 2000hours' |
| LD Deinceps current | SI* | - | - | 1100 | ma | - |
| LD Reverse current | IR | - | - | 10 | uA* | - |
| LD Reverse voltage | VR | - | - | 2 | V | - |
| PD Deinceps current | IPD | - | - | -10 | ma | - |
| PD Reverse voltage | VPD | - | - | 20 | V | - |
| TEC Current | ITEC | - | - | 2 | A | - |
| TEC Voltage | VTEC | - | - | 3.0 | V | - |
| Radii fibra inflexio | - | 30 | - | - | mm | - |
| Relativum humiditas | RH | 0 | - | 95% | - | Non condensatione |
| Ducere solidatorium Tempus | - | - | - | 10 | Secundus | 260℃ |
| Fibra articulatio viverra vi | - | - | - | 5 | N | - |
| Fibra parte viverra vi | - | - | - | 2.5 | N | - |
| Morbi laoreet | Symbolum | Min. | Typ. | Maximilianus. | Unitas | Notae |
| LD Limen current | ITH' | 90 | 110 | ma | CW | |
| Output potentia | PF | 400 | mW* | Si (BOL) <900mA | ||
| 600 | Si(BOL)<1000mA | |||||
| LD Deinceps current | SI* | 1200 | ma | PF = Rated Power | ||
| Kink liberam potestatem | PKINK | 700 | mW* | >= 1.2* Rated Power | ||
| MACULA liberum current | IKINK | >= 1.2*Si(BOL) | ma | [ 1 ] | ||
| LD Deinceps voltage | VF | 2.5 | V | PF = Rated Power | ||
| Centrum adsum | λC | 973 | 974 | 975 | nm | Apicem, PF=Rated Power |
| 975 | 976 | 977 | ||||
| Apicem adsum flexus | λp/△Tamb | 0.02 | nm/ | T: FBG Temp. | ||
| Imaginis latitudo | λ | 2 | nm | RMS@-13dB | ||
| Spectrum stabilitatis | -0.5 | 0.5 | nm | PF=Rated Power,t=60s | ||
| Monitor responsabilitas | IM/PF | 1 | 20 | uA/mW* | VPD=5V, PF=Rated Power | |
| Monitor responsabilitas stabilitatis | 20% | @All Operating Temperature | ||||
| Monitor tenebris current | ID | 50 | nA | VPD=5V | ||
| TEC Current | ITEC | 1.5 | A | TCASE=75℃ | ||
| TEC Voltage | VTEC | 3.0 | V | TCASE=75℃ | ||
| TEC | P | 5 | W | TCASE=75℃ | ||
| Potestas stabilitatis >20mW 10-20mW3.5-10mW | 0.20.51 | dB* | Peak-ad-apicem, t=60s, DC ad 50kHz sampling, TC=25℃ | |||
| Error tracking | TE | -0.5 | 0.5 | dB* | TC=-5~75℃, Refertur ad [2]. | |
| Thermistor resistentia | RTH | 9.5 | 10 | 10.5 | Kohm | TSTG=25℃ |
| Thermistor B constant | BTH | 3900 | k | TSTG=25℃ | ||
Notae:
[1] Kink Current definitur esse currente qui deviatio lucis versus slop(dL/dI) lineae aptus ultra +/-50%, Pkink>= 1.2*Rated Power,Ikink>=Si(BOL)*1.2
[2] Semita erroris temperatura in casu data definitur, est mutatio fibrarum potentiarum, stante monitore currente, quoad valorem mensuratum in casu 25℃
| Morbi laoreet | Descriptio |
| Genus fibra | Hi1060 vel PM980 fibra |
| Pigtail genus | Nudus fibra |
| Pigtail longitudo | 2.0±0.2m |
| Connector type | Sine |
| PIN | Descriptio | PIN | Descriptio |
| 1 | TEC(+) | 10 | TEC(-) |
| 2 | Thermistor | 9 | Causa terrae |
| 3 | PDAnode | 8 | NC |
| 4 | PD Cathode | 7 | LD Cathode |
| 5 | Thermistor | 6 | LD Anode |
| BFLD | -XXXF | -XX | XX | -X | XX | X |
| Laser | Necem | Output potentia | Genus fibra | sarcina | Connector type | tubus solve |
| PumpLaser | 974: 974nm976: 976nm | 4H: 400mW6H: 600mW | SM: Unius modePM: Polarizationmaintaining | -H: 10PINNull: 14PIN | FA : FC/APCSA : SC/APCN0: Null | Null: nuda fibra I: solve tube |
